Semi-Centrifugal Stainless Steel Grape Crusher-Destemmer - 3,000–4,000 kg/h
Right of withdrawal
You have 14 calendar days to withdraw from your purchase, with no need to give a reason. More information
The semi-centrifugal stainless steel grape crusher-destemmer is designed for grape crushing and destemming and is supplied without a transfer pump. The machine is made entirely of stainless steel and has an indicative output of 3,000–4,000 kg/h.
The destemming system features a professional deep-drawn screen with flared round holes and a destemming shaft fitted with rubber-coated paddles. The shaft operates at approximately 400–600 RPM.
Crushing is carried out by a pair of adjustable rubber rollers, designed to provide gentle pressing. The machine also includes a must collection tank and a mixing and feed screw for connection to an external pump.
Technical features
- Construction: entirely stainless steel;
- Motor: 2.5 HP (1.8 kW);
- Destemming shaft: rubber-coated paddles;
- Shaft speed: 400–600 RPM;
- Destemming screen: deep-drawn screen with flared round holes;
- Must collection tank: included;
- Rollers: adjustable rubber rollers;
- Safety housing: included;
- Pump connection: Ø60;
- Hourly output: 3,000–4,000 kg/h;
- Dimensions: 130 × 70 × 115 cm;
- Weight: 120 kg.
Optional equipment
- Pulley speed variator;
- Electronic speed variator;
- Food-grade rubber loading hopper screw.
- Processing capacity
- 2000 - 4000 kg/h
- Material
- Stainless steel
- Destemming screen
- Stainless steel
- Motor
- 2.5 HP (kW 1.8)
- Overall dimensions
- 1390 × 800 × 1320 / 1370 mm
- Weight
- 160 kg
- Shaft speed
- 400-600 RPM
- Crushing rollers
- Adjustable rubber crushing rollers
- Power source
- Single-phase / Three-phase
- Pump
- Nothing
- Pump head
- N.D.
- Product type
- Semi-centrifugal grape destemmer-crusher
